Product Details
- Size: 5
- Place of Origin: HEBEI
- Brand Name: Shijiazhuang Coal Mining Machinery
- Model Number: QYS-12IV
- Weight: 20000.000 kg
| Description | QYS-12IV |
| Max. Lifting Capacity (kg) | 12000 |
| Max. Lifting Moment (KN/m) | 360 |
| Max. Lifting Height (m) | 15.2 |
| Max. Working Radius (m) | 14.2 |
| Lifting Capacity (kg/m) | 12000/3, 8300/4.2, 1600/14.2 |
| Sections of Boom | 4 |
| Front Trigger (Action/ Span) | Hydraulic/2.2-5.5 |
| Rear Trigger (Action/ Span) | Hydraulic/2.2-4.2 |
| Hoisting Mechanism | Motor driven, planet gear reducing, inner mechanical brake and valve lock |
| Swivel Mechanism | Motor driven, planet gear reducing, inner mechanical brake and valve lock |
